Trek
Price €1.799,00
Available colours
Frame shape
DiamondLease this bike through your employer. Calculate the lease price per month
€
€
Please note: the stated lease and sales prices are indicative. The sales price of the (web)shop is leading for the final lease price.
Costs per month from
Specifications
+−
In general
Model year
2027
Rear wheel size
29
Front wheel size
29
Fork
Fork brand
Fox
Fork model
Fox Rhythm 34, Float EVOL luchtvering, GRIP-demper, taps toelopende stuurbuis, 44 mm offset, Boost110, 15 mm Kabolt-as, 120 mm veerweg
Stem
Stem brand
Bontrager
Stem model
Bontrager Elite, 31,8 mm, geschikt voor Blendr, 7 graden, 60 mm lengte
Chain
Chain brand
Shimano
Chain model
Shimano Deore M6100, 12-speed
Frame
Frame size
44
Frame type
Uni
Frame material
Carbon
Frame size
ML
Gears
Gear type
Derailleur
Gear brand
Shimano
Gear model
Shimano Deore M6200, lange kooi
Number of gears
1
Tyres
Tyre brand
Maxxis
Tyre model
Maxxis Rekon Race, Tubeless Ready, EXO karkas, vouwband, 60 tpi, 29x2.40"
Saddle
Saddle brand
Merkloos
Saddle model
Verse Short, stalen rails, 145 mm breedte
Wheels
Wheels model
Bontrager Kovee, dubbelwandig, Tubeless Ready, 28-gaats, 23 mm velgbreedte, Presta-ventiel
Shimano TC500 lichtmetaal, centerlock, 110 x 15 mm steekas
Shimano TC500 lichtmetaal, centerlock, 148 x 12 mm steekas
Headset
Headset brand
FSA
Headset model
FSA IS-2, 1-1/8" bovenzijde, 1.5" onderzijde
Cassette
Cassette brand
Shimano
Cassette model
Shimano M6200, 10-51, 12 versnellingen // Shimano XT M8100, 10-51, 12-speed
Crankset
Crankset brand
Shimano
Crankset model
Shimano MT520, 32T kettingblad, 55 mm kettinglijn, 170 mm lengte
Shimano MT500, 92 mm, PressFit
Geometry
Offset
4.3
Wheelbase
115.5
Head angle
67
Frame reach
44.5
Frame stack
61.4
Top tube length
61.3
Seat tube angle
72
Chainstay length
43.5
Head tube length
9
Seat tube length
44
Stand over height
75.8
Bottom bracket drop
6.4
Bottom bracket height
30.9
Seatpost
Seatpost brand
Bontrager
Seatpost model
Bontrager Line Dropper, 150 mm verstelbereik, MaxFlow, interne kabelvoering, 31,6 mm, 410 mm lengte
Shifters
Shifters brand
Shimano
Shifters model
Shimano Deore M6200
Handlebar
Handlebar brand
Bontrager
Handlebar model
Bontrager Rhythm Comp, lichtmetaal, 31,8 mm, 15 mm rise, 750 mm breedte
Front brake
Front brake type
Schijfrem met hydraulische bediening
Front brake brand
Shimano
Front brake model
Shimano hydraulische schijfrem, MT4100 hendel, MT410 remklauw // Shimano hydraulische schijfrem, MT4100 hendel, MT410 remklauw // Shimano MT200 hydraulische schijfrem // Shimano MT200 hydraulische schijfrem // Shimano hydraulische schijfrem, M
Shimano RT10, centerlock, 160 mm // Shimano RT10, centerlock, 160 mm
Maximale diameter re
Seatpost clamp
Seatpost clamp brand
Merkloos
Seatpost clamp model
Schroefconstructie, 36,4 mm
Rear derailleur
Rear derailleur brand
Shimano
Rear derailleur model
Shimano Deore M6200, lange kooi
Bar tape/Grips
Bar tape/Grips brand
Trek
Bar tape/Grips model
Trek Line Comp, nylon lock-on
Rear brake
Rear brake type
Schijfrem met hydraulische bediening
Rear brake brand
Shimano
Rear brake model
Shimano hydraulische schijfrem, MT4100 hendel, MT410 remklauw // Shimano hydraulische schijfrem, MT4100 hendel, MT410 remklauw // Shimano MT200 hydraulische schijfrem // Shimano MT200 hydraulische schijfrem // Shimano hydraulische schijfrem, M
Shimano RT10, centerlock, 160 mm // Shimano RT10, centerlock, 160 mm
Maximale diameter re
