Trek
Price €3.899,00
Available colours
Battery options
Frame shape
DiamondLease this bike through your employer. Calculate the lease price per month
€
€
Please note: the stated lease and sales prices are indicative. The sales price of the (web)shop is leading for the final lease price.
Costs per month from
Specifications
+−
In general
Model year
2027
Rear wheel size
29
Front wheel size
29
Fork
Fork brand
Rockshox
Fork model
RockShox Recon Silver RL, Solo Air, Motion Control demper, lock-out, taps toelopende stuurbuis, 42 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm veerweg
Stem
Stem brand
Bontrager
Stem model
Bontrager Rhythm Comp, 31,8 mm, 0 graden, 50 mm lengte
Chain
Chain brand
Shimano
Chain model
Shimano Deore M6100, 12-speed
Frame
Frame size
42
Frame type
Uni
Frame material
Aluminium
Frame size
L
Gears
Gear type
Derailleur
Gear brand
Shimano
Gear model
Shimano Deore M8200, lange kooi
Number of gears
1
Tyres
Tyre brand
Bontrager
Tyre model
Bontrager Gunnison Elite XR, Tubeless Ready, stalen hieldraad, 60 tpi, 29 x 2.40”
Pedals
Pedals brand
Merkloos
Pedals model
Nylon platform
Saddle
Saddle brand
Bontrager
Saddle model
Bontrager Commuter Comp
Wheels
Wheels model
Bontrager Kovee, dubbelwandig, Tubeless Ready, 28-gaats, 23 mm velgbreedte, Presta-ventiel // Bontrager Kovee, dubbelwandig, Tubeless Ready, 32-gaats, 23 mm velgbreedte, Presta-ventiel
Shimano TC500 lichtmetaal, centerlock, 110 x 15 mm steekas
Shimano TC500 Aluminium, Centerlock, 148x12 mm steekas // Shimano TC500 lichtmetaal, centerlock, 148 x 12 mm steekas
Headset
Headset brand
FSA
Headset model
FSA IS-2, 1-1/8" bovenzijde, 1.5" onderzijde
Cassette
Cassette brand
Sunrace
Cassette model
SunRace CSMZ800 11-51, 12 speed // Shimano XT M8100, 10-51, 12-speed
Crankset
Crankset brand
Merkloos
Crankset model
FSA-legering, lengte 160 mm
Geometry
Trail
11.7
Offset
4.4
Wheelbase
122.6
Head angle
66.5
Frame reach
46.5
Frame stack
65.5
Top tube length
64
Seat tube angle
73.4
Chainstay length
46.1
Head tube length
12.3
Seat tube length
42
Stand over height
74.6
Bottom bracket drop
6.5
Bottom bracket height
31.5
Seatpost
Seatpost brand
TranzX
Seatpost model
TranzX JD-YSI34, verstelbereik 170 mm, interne kabelgeleiding, 31,6 mm, lengte 500 mm
Shifters
Shifters brand
Shimano
Shifters model
Shimano Deore M6200
Handlebar
Handlebar brand
Bontrager
Handlebar model
Bontrager Comp, lichtmetaal, 31,8 mm, 40 mm rise, breedte 780 mm
Front brake
Front brake type
Schijfrem met hydraulische bediening
Front brake brand
Shimano
Front brake model
Shimano hydraulische schijfrem met vier remzuigers, MT4100 hendel, MT420 remklauw // Shimano hydraulische schijfrem met vier remzuigers, MT4100 hendel, MT420 remklauw // Shimano hydraulische schijfrem, MT4100 hendel, MT420 remklauw met vier rem
Shimano RT64, centerlock, 203 mm // Shimano RT64, centerlock, 203 mm
Maximale maten remsc
Seatpost clamp
Seatpost clamp brand
Merkloos
Seatpost clamp model
Schroefconstructie, 36,4 mm
Rear derailleur
Rear derailleur brand
Shimano
Rear derailleur model
Shimano Deore M8200, lange kooi
Bar tape/Grips
Bar tape/Grips brand
Bontrager
Bar tape/Grips model
Bontrager XR Endurance Comp, lock-on
Rear brake
Rear brake type
Schijfrem met hydraulische bediening
Rear brake brand
Shimano
Rear brake model
Shimano hydraulische schijfrem met vier remzuigers, MT4100 hendel, MT420 remklauw // Shimano hydraulische schijfrem met vier remzuigers, MT4100 hendel, MT420 remklauw // Shimano hydraulische schijfrem, MT4100 hendel, MT420 remklauw met vier rem
Shimano RT64, centerlock, 203 mm // Shimano RT64, centerlock, 203 mm
Maximale maten remsc
E-bike Specifications
+−
In general
E-bike type
Normaal
Walk assist
Yes
spec_handle_control
Yes
Drivetrain brand
Bosch
Order without battery
No
Order without charger
No
spec_order_without_display
No
Engine
Engine brand
Bosch
Engine model
Bosch Performance Line CX (Europa en APAC: 25 km/u, VS en ROW: 32 km/u)
Charger
Charger brand
Bosch
Charger model
Bosch standaard 4A, 230V, smart system
Display
Display brand
Bosch
Display model
Bosch Purion 200
spec_operation_type
Stuurbediening (Midden)
